| TECHNICAL DATA: | |
| Measuring Technique: |
Magnetic induction (ISO 2178) on ferrous base material |
| Measuring Range: |
0 - 2000 µm |
| Resolution: |
0,1 µm (0 - 100 µm) / 1 µm (100 - 2000 µm) |
| Accuracy: |
< 100 µm = ± 1 µm / 100 - 1000 µm = ± 1% / > 1000 µm = ± 3% |
| Display: |
LCD 3½ - digit |
| Power Supply: |
9V battery or rechargeable (IEC 6 LF 22) |
| Operating Time: |
approx. 50 hrs. |
| Data Logger: |
250 readings |
| Interface: |
Serial RS 232 |
| Dimensions: |
70 x 120 x 28 mm |
| Weight: |
approx. 170 g |
| Optionals: | |
| | Standard Paper Printer DUO-PRINT |
| | Data transmission program TRANSFER |
| | Data evaluation program STAT-5 |
